HG-750Q Double carved machine

HG-750Q Double carved machine

HG-750Q carved machine is CNC engraving machine specialized for mobile phone glass, toughened membrane, plastic back cover, acrylic materials .Widely used in mobile phone manufacturing, mobile phone..

tel us:  (86)0769-82819981

Introduction Specification Date download

Product introduction
HG-750Q chooses excellent Bao yuan/ Delta servo motor as a driving force,and goes with Silver/Yintai imported grinding ball screw and guide rail, can do the three-dimensional cutting for aluminum sheet, stainless steel, ABS, PVC, epoxy resin, synthetic stone and other materials. Applicable to high light, panel chamfering,cutting,trimming for mobile phones, digital cameras, MP3, MP4, DVD, PDA and other products, also can be used for processing of palm, signs, models, relief, fixture and so on.

Common names
HG-750Q Mobile phone back cover engraving machine
HG-750Q Acrylic engraving machine
HG-750Q PE Engraving machine
HG-750Q PVC Engraving machine

Application of the industry

Huaxin carved machine is widely used in mobile phone manufacturing, mobile phone accessories processing, glass handicraft production, acrylic craft production.

Application scenarios

Huaxin carved machine can be used in mobile phones glass and mobile phone screen plate processing, mobile toughened film processing, mobile phone plastic back cover sculpture, glasses glass grinding processing, acrylic and PC material processing, luminous characters and crystal production and processing.

Characteristics of the equipment
1.Main structure of Machine tool: adopt high quality marble, good effect of shock absorption ,not affected by temperature, high machining accuracy, perfect stability when high speed running.

2.Major parts: silver/Yintai high precision ball screw (0.008/0.0005/300), silver/Yintai precision linear guide, bao yuan/of servo motor, frequency converter from Taiwan, Japan omron/chengtai/delixi high precision electrical accessories, carved in control system, 1.8 W 60000 changed hands moving high-speed spindle.

3.Control software: Chinese interface, running under WINDOWS system, can receive standard 3 d G code format and HP PLT and Type3 CAXA CAD format, can directly accept Cimatron, MasterCAM, UG, etc all kinds of original post processing, can also connected with 2d design software such as AUTOCAD, Core/DRAW , it also has 3 d dynamic display tracking, automatic knife, jump for execution (breakpoint memory function, easy and quick operation.

4.Lubricating systems: the screw on the machine tool, the precision of guide rail and other key parts are equipped with oil, manual control for its oil supply, working state can be maintained.

5.Dustproof system: precision machine tools on the screw, guide rail and other key parts have dustproof accessories, dust protection well.

6.Projection alarm function: power over-voltage and under-voltage protection alarm function . Servo motor, inverter and other protection alarm function.

7.The knife system: Automatic and manual operation both available.



Main Spindle speed


Numerical control system

Bao yuan/Of system

Quantity of main spindle

1 set

Shape Dimension


Spindle chuck


Server system

Bao yuan/Of servo motor

Spindle power


Table size


Rated voltage


Triaxial working stroke


Worktable load


System resolution


Height can be loaded


positioning accuracy


Maximum power of the machine


Repeat positioning accuracy


Machine weight


Three-axis verticality


Maximum processing speed


Maempty walking speed
